Thermacheck

Product comparison

ThermaCheck	Product name	TC-160 LT	TC-160	TC-320 PRO	TC-160 M1
Product specifications	Product feature	Handheld & Self-contained monitor	Supporting network & multi-target	Supporting network & multi-target	Mask Alert & no PC needed
	Temperature Range	34-42°C( 93 - 108˚F )	Optimal::33-40°C( 91 - 104˚F ) Max: 28-45°C ( 82 - 113˚F )	Optimal::33-40°C( 91 - 104˚F ) Max: 28-45°C ( 82 - 113˚F )	28-45°C ( 82-113˚F )
	Temperature Accuracy	≤±0.5°C	Without Blackbody:≤ ±0.3°C	Without Blackbody:≤ ±0.3°C	±0.3°C(±0.5˚F )
	Measurement Distance	0.6-1.8m	1–4m	1.8–6m	1–4m
	Calibration	Human subject	Human subject or blackbody	Human subject or blackbody	Human subject or blackbody
	Target Mode	Single	Single or Multiple Person(~10 people max)	Single or Multiple Person	Single or Multiple Person(~10 people max)
	Intelligent Tracking	Automatic tracking and highest temperature readout	Automatic tracking and highest temperature readout	Automatic tracking and highest temperature readout	Automatic tracking , highest temperature readout and Mask Alert
	Temperature Alert	User defined threshold value	User defined threshold value	User defined threshold value	User defined threshold value
Thermal Camera	Sensor Technology	Uncooled Vox Microbolometer	Uncooled Vox Microbolometer	Uncooled Vox Microbolometer	Microbolometer
	Resolution	160 x 120	160 x 120	336 x 256	160 x 120
	NETD	<50 mK（0.050°C）	<50 mK（0.050°C）	<50 mK（0.050°C）	<50 mK（0.050°C）
	FOV	57°X44˚	57°X44˚	25°X19°(13mm))	57°X44.3°
	Color Palette	Iron red, Gray, Rainbow, and Flame (red on gray)	Iron Red	Iron Red	Iron Red
Visible Camera	Sensor Technology	No visible camera sensor	1/2.9inch CMOS	1/2.9inch CMOS	1/2.8inch CMOS
	Pixel Size	No visible camera sensor	2MP	2MP	2MP
	Resolution	No visible camera sensor	1920*1080	1920*1080	1920*1080
	Low Light Level	No visible camera sensor	Color:0.1Lux@(F1.2)/B&W:0.01Lux@(F1.2)	Color:0.1Lux@(F1.2)/B&W:0.01Lux@(F1.2)	Color:0.01Lux@(F1.5)
	Wide Dynamic	No visible camera sensor	Supported	Supported	Supported
	Color Balance	No visible camera sensor	Supported	Supported	Supported
	DNR	No visible camera sensor	3D DNR	3D DNR	3D DNR
General	Operating Temperature	18-26˚C(64 – 79 ˚F))	0-45°C(50 - 113˚F) /Preferred:16-32°C(60 - 90˚F)	0-45°C(50 - 113˚F) /Preferred:16-32°C(60 - 90˚F)	0-45°C(50 - 113˚F) /Preferred:16-32°C(60 - 90˚F)
	Humidity	EC 60068-2-30 / 24h 85％RH	EC 60068-2-30 / 24h 85％RH	EC 60068-2-30 / 24h 85％RH	EC 60068-2-30 / 24h 85％RH
	Power	1500 mAH Lithium polymer battery	Input: 100-240V AC, Output: 15V 2A DC	Input: 100-240V AC, Output: 15V 2A DC	Input: 100-240V AC, Output: 15V 2A DC
	Dimension	125 x 72 x 16mm	95 x 88 x 40mm	86 x 105 x 144mm	130 x 90 x 45mm
	Weight	180g	348g	1200g	465g
	IR Illuminator	No	No	5watt 850nm LED	No
	Self-contained monitor	3.5inch TFT LCD monitor(480x320)	No, requires computer connection, or internal network	No, requires computer connection, or internal network	Requires display with HDMI connection
